Packaging, Protection, Storage
Our ZOUCHprotekt series extruded profiles are manufactured from Polyethylene foam created to protect your products, covering market requirements in many applications and in different industrial sectors. They include the furniture industry and white goods. These products contain no CFC or HCFC blowing agents and are fully recyclable. Our simple, effective profile designs are developed to solve all your packaging problems.
The ZOUCHprotekt profiles have a regular and even structure of closed cells which are isolated and air-filled to maintain articles packaged, protected and in optimum condition, providing security and protection for a better presentation.
The ZOUCHprotekt range is highly resistant to blows, recovering its original shape after absorbing the impact. They are lightweight in nature, highly resistant and flexible, and easily adapted to each product for quick and easy handling. We can also design and develop the ideal profile as you require.
Available as stock in over twenty different profile sizes and standard in 2 meter lengths, our ZOUCHprotekt extruded profiles are an ideal solution for giving superb protection transporting new and expensive goods.
ZOUCHcork Spacer Pads
ZOUCHcork spacer pads are made from natural moulded cork, grinded and bonded with adhesive, covered with a self adherent foam laminate. The cork-foam combination is particularly suitable for the flexible and accurate cushioning between the glass sheets. Adequate choice of the ZOUCHcork distance pad type and thickness can enable to meet different conditions and demands.
ZOUCHcork is also available as a bobbin wound spool for the processing with Lisec and Lenhardt automatic pad dispensing machines.
Click here to view/download product brochure
ZOUCHglaze Spacer Pads
ZOUCHglaze spacer pads are single sided adhesive coated foam products incorporating a peelable UV stable acrylic adhesive and a high density PVC foam. Various colours are available subject to minimum order quantity but standard in Red or Blue. The high density material provides excellent shock absorption and the low compressibility of the pad allows layers of glass to remain separated at all times at both low and elevated temperatures.
Click here to view/download product brochure
ZOUCHprotekt Extruded PE foam profiles
Our ZOUCHprotekt series extruded profiles are manufactured from Polyethylene foam created to protect your products, covering market requirements in many applications and in different industrial sectors. They include the furniture industry and white goods. These products contain no CFC or HCFC blowing agents and are fully recyclable. Our simple, effective profile designs are developed to solve all your packaging problems.
The ZOUCHprotekt profiles have a regular and even structure of closed cells which are isolated and air-filled to maintain articles packaged, protected and in optimum condition, providing security and protection for a better presentation.
The ZOUCHprotekt range is highly resistant to blows, recovering its original shape after absorbing the impact. They are lightweight in nature, highly resistant and flexible, and easily adapted to each product for quick and easy handling. We can also design and develop the ideal profile as you require.
Available as stock in over twenty different profile sizes and standard in 2 meter lengths, our ZOUCHprotekt extruded profiles are an ideal solution for giving superb protection transporting new and expensive goods.
Benefits & Features
- Standard in 2 meter lengths
- Re-usable
- CFC & HCFC Friendly
- Non-Toxic
- Can be cut easily to fit edges or surfaces.
- Self Gripping
- Protection during transport, shipping or storage
- 100% Recyclable
- Flexible, lightweight material and easy to install
- Highly resistant to chemicals
- Commonly used in the Furniture, Automotive, Glazing, Electrical and White Good sectors
- iAvailable in 30 Kgs/m3 as standard or 60 Kgs/m3 density for higher performance applications subject to minimum order
Colours
Standard in Blue. Custom colours available and can be matched upon request subject to minimum order quantity.
Manufacturing Process
Chemically expanded to give cellular structure
Cell Structure
Non Cross-Linked Closed Cell
Packaging
Standard profile length is 2 meters long packaged in double wall cardboard cartons with approximate dimensions of 625mm wide x 415mm high x 2050mm Long.
Click here to view/download product brochure
ZOUCHlen 110
A single-sided low to medium density physically cross-linked Polyethylene foam with closed cells which is appropriate for sealing, insulation, protecting and soft storing applications. Will seal out condensation, air, light and dust. ZOUCHlen 110 is ideal where cost is a critical factor.
Click here to view/download product brochure
ZOUCHlen 111
A single-sided physically cross-linked flexible soft Polyethylene foam with closed cells, reinforced by a fixed film laminate to help eliminate stretch of material and improve the tensile strength when in application. “Quick Roll” enables rapid and improved working without the need of a release liner. ZOUCHlen 111 is commonly used for sealing, insulating, protecting and soft storing applications. For a Flame Retardant version see ZOUCHlen 111-G.
Click here to view/download product brochure
ZOUCHlen 111 W
ZOUCHlen 111 - W is primarily a white foam compression sealant, it is predominantly closed cell and has a rubber pressure sensitive adhesive coating on one side and a polyethylene fixed liner on the other non-adhesive face. This product is clean to use and offers a clean edge finish and is suitable for both indoor and outdoor applications.
The superior qualities of ZOUCHlen 111 - W which include a high quality pressure-sensitive rubber resin adhesive, good resistance to dilute acids and alkalis, very good UV resistance as well as resistance to abrasion, corrosion and moisture make it ideal to act as a weather seal and air/dust seal when compressed. It is often used for preventing electrolytic corrosion, for cushioning, for gap filling and for anti-slip mounting.
Click here to view/download product brochure
ZOUCHlen 120
A single-sided physically cross-linked flexible Polyethylene foam with closed cells and a smooth surface, coated with a synthetic rubber adhesive reinforced by a scrim thread. The product is commonly used for hand placing in window glazing. ZOUCHlen 120 is also used for many sealing (dust & draught), insulating, protecting and soft storing applications. It also can be used as a cold-bridging tape within the roofing sector or as a partition wall tape due to its superior conformability and compressibility which allows it to adhere well to textured and irregular surfaces. Not recommended where there is constant direct exposure to UV light. ZOUCHlen 120 is a budget solution if costs are an issue.
Click here to view/download product brochure
ZOUCHlen 122
Consists of a single-sided physically cross-linked flexible low density Polyethylene foam with closed cells and an EVA additive to give the product extra elasticity. The product is used for sealing, cushioning, and sound absorption and also serves as protection and insulation. The EVA foams are generally more resilient, tougher and stronger than the conventional Polyethylene foams.
Click here to view/download product brochure
ZOUCHlen 210
Consists of a one side self adhesive cross-linked closed cell Polyethylene foam with a firm density. The product is designed for use in the most demanding foam sealing or cushioning applications. High internal strength resists pressure from outside forces and high hardness (65 shore 00) resists deterioration.
Click here to view/download product brochure
ZOUCHlen T19/08
A single-sided physically cross-linked flexible polyethylene foam with closed cells, reinforced by a fixed polyester film which allows the cover to glide over the frame preventing abrasion and snagging of the cover during construction of polytunnels. It will also help eliminate stretch of material and improve the tensile strength when in application. ZOUCHlen T19/08 is commonly used as an anti hot-spot tape for polythene tunnel greenhouses.
Click here to view/download product brochure
ZOUCHmask 1199
ZOUCHmask 1199 is a crepe paper, coated with a rubber-based pressure-sensitive adhesive. ZOUCHmask 1199 is a proven industry leading tape that is a fantastic all-round masking tape. It is designed primarilly as an all-purpose product for non-critical applications within the building, painting and D.I.Y market.
Click here to view/download product brochure
ZOUCHmask 1210
ZOUCHmask 1210 is a high-quality blue creped paper masking tape. The special adhesive provides clean removability from a wide variety of surfaces, for up to 14 days. This product offers excellent UV resistance. ZOUCHmask 1210 is designed primarily as an all-purpose product for non-critical applications within the building, painting and D.I.Y market; this tape is excellent for even the most demanding of paint application.
Click here to view/download product brochure
ZOUCHmask ST 65
ZOUCHmask ST 65 is a high-quality single-sided polyethylene tape with serrated edges for easy tearing. This product is highly conformable and flexible, offers 30 day clean removal and bonds well to glass, aluminium, plastic and wood. ZOUCHmask ST 65 is designed primarily as an all-purpose product for outdoor masking applications, stucco and plaster masking as well as for surface protection.
Click here to view/download product brochure
ZOUCHprotekt 1265 and ZOUCHprotekt 1366
ZOUCHprotekt 1265 and ZOUCHprotekt 1366 surface protection tapes are high-quality, transparent polyurethane films with superior resistance to ultra-violet radiation coated one side with pure acrylate-based adhesive. Our ZOUCHprotekt surface protection films are extraordinarily resistant to abrasion as well as possessing excellent dampening properties. They have excellent tensile strength and mechanical disruptive strength; the films can be printed on or painted over with high quality varnishes.
Click here to view/download product brochure
ZOUCHseal 90
A single-sided super soft low density semi-open cell lightweight PVC Foam sealant with a very smooth finish which will conform to irregular surfaces and curves. Very high ageing and UV resistant product with a low force to compress. “Quick Roll” enables rapid and improved working and eliminates stretching during installation. Used for sealing air and condensation when compressed, cushioning, gap filling or as a light, dust and draught seal.
Click here to view/download product brochure
ZOUCHseal 100
A single-sided low density soft PVC Foam sealant with mostly closed cells and a very smooth surface. The tape provides an excellent combination of flexibility and conformability and is used for all kinds of indoor and outdoor sealing applications. The special design of the tape “Quick Roll” enables rapid and improved working and also prevents stretching during installation. Very high ageing and UV resistant product used for sealing, insulating for heat and cold, protecting and soft storing applications.
Click here to view/download product brochure
ZOUCHseal 115-G
Single-sided low density PVC foam sealant. This product is a white open-celled soft and flexible foam with pressure-sensitive acrylic adhesive one side and a fixed polyester liner on the non-adhesive face.
Click here to view/download product brochure
ZOUCHseal 160
A single-sided medium density flexible PVC Foam sealant with mostly closed cells and a very smooth surface. Often used in HVAC applications for sealing and cushioning and for truck cab & body seals. It has excellent dimensional stability and insulates against temperature. The tape provides an excellent combination of flexibility and conformability with both strength and wear resistance as a main factor. It will perform in those “tough duty” applications where a tape must still be flexible to fit and seal. The special design of the tape “Quick Roll” enables rapid and improved working and prevents stretching during installation. Again, like the majority of our ZOUCH insulation tapes, the ZOUCHseal 160 is totally UV stable.
Click here to view/download product brochure
ZOUCHseal 200
A single-single medium to firm density flexible PVC Foam sealant with mostly closed cells and a very smooth surface finish. ZOUCHseal 200 is mainly used as a seal, shock or vibration absorber due to its excellent conformability and tensile strength. It is UV stable and has very good ageing properties against moisture, corrosion and abrasion. The special design of the tape “Quick Roll” enables rapid and improved working and prevents stretching during installation.
Click here to view/download product brochure
ZOUCHseal 260
A single-sided high density flexible UV stable PVC Foam sealant for a higher demanding and load bearing application. The tape will provide an excellent combination of flexibility and conformability with good strength and wear resistance. Performs in those “tough duty” applications where a tape must still flex to fit and seal. The special design of the tape “Quick Roll” enables rapid and improved working and prevents stretching during installation.
Click here to view/download product brochure
ZOUCHflex CM-A
ZOUCHflex CM-A is a soft closed-cell cross-linked foam rubber which is self-adhesive on one side. This product offers a cheaper alternative to our ZOUCHflex CM-L (pure EPDM sponge) by reducing the density.
Click here to view/download product brochure
ZOUCHflex CM-L
A single-sided self-extinguishing medium density EPDM Sponge rubber with closed cells and excellent recovery under pressure. It has very good ageing, weathering and ozone resistance along with an excellent working temperature. Not recommendable is long term contact with mineral oils and fats, nonpolar and chlorinated solvents, aromatics and strong oxidized acids. Being a closed cell material, ZOUCHflex CM-L will not penetrate any water or liquids and has excellent UV and Ozone resistance. This product is a cost effective economical material which can also be used as a shock absorber due to the excellent cushioning characteristics it inherits. ZOUCHflex CM-L has excellent weather resistance and can be used as a non slip backing material for applications such as mouse-mats and coasters. Additional uses for roofing, heat insulation seals, air conditioners and refrigerator showcase seals and many civil engineering, construction and vehicle applications.
Click here to view/download product brochure
ZOUCHflex CM-RN
ZOUCHflex DK
A single-sided medium density Black blended sponge rubber with closed cells and excellent recovery under pressure. ZOUCHflex DK is based on a polymeric blend of Neoprene and Nitrile compounds and is oil, chemical and acid resistant along with flame retardant to a more vigorous standard. This unique material has a very fine cell structure and a broad temperature range. It has excellent dimensional stability and being a closed cell material; ZOUCHflex DK will not penetrate any water or liquids and also has excellent UV and Ozone resistance. Heavily certified to a number of OEM’s including General Motors and Chrysler and complies with Underwriters Laboratories (UL) for various safety standards. Used for many critical sealing, insulating and damping applications that requires certifications or approvals of conformity.
Click here to view/download product brochure
ZOUCHflex F-180
A single-sided medium density natural sponge rubber with closed cells and excellent recovery under pressure. It exhibits good conformability with excellent dimensional stability and will maintain its physical properties under various conditions. Being a closed cell material, ZOUCHflex F-180 will not penetrate any water or liquids. The product is extensively used for sealing, damping, and insulating, protecting and soft storing applications.
Click here to view/download product brochure
ZOUCHflex NF 150
A single-sided medium density pure Grey neoprene sponge rubber with closed cells. This product is inherently resistant to chemicals, acids and oils along with its excellent flame retardant properties according to FMVSS 302 and UL94 HBF makes this product the ideal material choice for the automotive sector. Being a closed cell material, ZOUCHflex NF 150 will not penetrate any water or liquids and has excellent UV and Ozone resistance. It also has very good high ageing properties and restoring forces and will not crack or become brittle over time. Used for many critical sealing, insulating and damping applications.
Click here to view/download product brochure
ZOUCHflex NW 152
A single-sided medium density pure Black Neoprene sponge rubber with closed cells and excellent recovery under pressure. This product is based on Polychloroprene and has excellent chemical, solvent and oil resistance along with good flame retardant features according to FMVSS 302. Being a closed cell material, ZOUCHflex NW 152 will not penetrate any water or liquids and has excellent UV and Ozone resistance. It also has a very broad temperature range. It is especially suited when flame resistance, oil and fat resistance or a high compressive strength is required. Furthermore, this product does not crack or become brittle over time or exhibit loss of properties. Used mainly for sealing, damping, insulating, protecting and soft storing applications.
Click here to view/download product brochure
ZOUCH eFoam
Zouch Converters eFoam products have obtained Eco Label (the certi cate of environmentally friendly product) of catergories 1 and 2, and meet the European Common Market RoHS requirements. It is produced with clean production processes that emphasize on the restraints of air, water, waste, toxicant, odour, noise and radiation. eFoam’s high weather-resistance and easy workability provides the customers with the bestquality and performance that effectively reduces the material and production costs.
Click here to view/download product brochure
ZOUCH WCT 3100
ZOUCH WCT 3100 is a utility grade poly-coated cloth duct tape, ideally suited for joining polythene and has many uses in numerous industries. This is our most popular cloth tape and has been the industry favourite for many years. Available in the following colours: - Silver, black, white, red, blue, yellow, green, brown, orange, tan and olive.
Click here to view/download product brochure
ZOUCH WCT 3120
ZOUCH WCT 3120 is a medium performance, strong, polyethylene coated waterproof cloth tape, coated with a pressure sensitive adhesive. This tape is used in a wide variety of applications, from duct sealing, heavy duty export packaging, double glazing unit sealing, carpet joining and fixing of cables and wires – it is ideal for general purpose applications where added strength and performance is required. The tape is available in a full range of colours including black, white, silver, grey, red, yellow, blue, green and brown.
Click here to view/download product brochure
