HVAC
Zouch Converters have a range of seals, gaskets and tapes that are heavily used within the heating, ventilation and air conditioning section. These high performing materials specifically designed for the insulation and sealing of ventilation and air conditioning ducts, meeting all the necessary requirements in terms of fire behaviour, structure and dimensions.
Duct sealing is the sealing of leaks in air ducts in order to reduce air leakage, optimise efficiency, and control entry of pollutants into the home or building. Air pressure combined with air duct leakage can lead to a loss of energy in an HVAC system and duct sealing solves issues of energy loss in the system.
Zouch Converters offer a comprehensive range of closed cell foams, ideal for round and flat-oval duct connections which are simple and easy to install, therefore producing an airtight seal. These materials can also be supplied as sheets or rolls, die-cut components or with a special surface lamination to enhance further the performance of the product.
Some typical acoustic applications:
- Duct lining
- Pipe insulation
- Heating enclosures
- Various HVAC duct work
- Air conditioning enclosures
Our technical sales team is available to assist with product recommendations based on your application needs.
ZOUCHflex CM-A
ZOUCHflex CM-A is a soft closed-cell cross-linked foam rubber which is self-adhesive on one side. This product offers a cheaper alternative to our ZOUCHflex CM-L (pure EPDM sponge) by reducing the density.
Click here to view/download product brochure
ZOUCHflex CM-L
A single-sided self-extinguishing medium density EPDM Sponge rubber with closed cells and excellent recovery under pressure. It has very good ageing, weathering and ozone resistance along with an excellent working temperature. Not recommendable is long term contact with mineral oils and fats, nonpolar and chlorinated solvents, aromatics and strong oxidized acids. Being a closed cell material, ZOUCHflex CM-L will not penetrate any water or liquids and has excellent UV and Ozone resistance. This product is a cost effective economical material which can also be used as a shock absorber due to the excellent cushioning characteristics it inherits. ZOUCHflex CM-L has excellent weather resistance and can be used as a non slip backing material for applications such as mouse-mats and coasters. Additional uses for roofing, heat insulation seals, air conditioners and refrigerator showcase seals and many civil engineering, construction and vehicle applications.
Click here to view/download product brochure
ZOUCHflex CM-RN
ZOUCHflex DK
A single-sided medium density Black blended sponge rubber with closed cells and excellent recovery under pressure. ZOUCHflex DK is based on a polymeric blend of Neoprene and Nitrile compounds and is oil, chemical and acid resistant along with flame retardant to a more vigorous standard. This unique material has a very fine cell structure and a broad temperature range. It has excellent dimensional stability and being a closed cell material; ZOUCHflex DK will not penetrate any water or liquids and also has excellent UV and Ozone resistance. Heavily certified to a number of OEM’s including General Motors and Chrysler and complies with Underwriters Laboratories (UL) for various safety standards. Used for many critical sealing, insulating and damping applications that requires certifications or approvals of conformity.
Click here to view/download product brochure
ZOUCHflex EL 55-70
ZOUCHflex EL 55-70 is a premium quality flexible closed cell elastometric sponge material which has a Nitrile base. It has excellent thermal properties making it ideal for pipe insulation and doesn’t crack or become brittle at exceptionally low temperatures. It is also dust free, fibre free and CFC friendly.
Click here to view/download product brochure
ZOUCHflex K
ZOUCHflex K is a single-sided highly compressible semi closed-cell NBR (Nitrile Blend) foam sealant supplied with or without a pressure-sensitive acrylic self-adhesive backing. The product conforms well to gaps with rough surfaces as well as to expansion and contraction caused by temperature change. ZOUCHflex K is commonly used for many sealing, insulating, protecting and noise reduction applications mainly within the automotive sector.
Click here to view/download product brochure
ZOUCHflex NW 152
A single-sided medium density pure Black Neoprene sponge rubber with closed cells and excellent recovery under pressure. This product is based on Polychloroprene and has excellent chemical, solvent and oil resistance along with good flame retardant features according to FMVSS 302. Being a closed cell material, ZOUCHflex NW 152 will not penetrate any water or liquids and has excellent UV and Ozone resistance. It also has a very broad temperature range. It is especially suited when flame resistance, oil and fat resistance or a high compressive strength is required. Furthermore, this product does not crack or become brittle over time or exhibit loss of properties. Used mainly for sealing, damping, insulating, protecting and soft storing applications.
Click here to view/download product brochure
ZOUCHflex NF 150
A single-sided medium density pure Grey neoprene sponge rubber with closed cells. This product is inherently resistant to chemicals, acids and oils along with its excellent flame retardant properties according to FMVSS 302 and UL94 HBF makes this product the ideal material choice for the automotive sector. Being a closed cell material, ZOUCHflex NF 150 will not penetrate any water or liquids and has excellent UV and Ozone resistance. It also has very good high ageing properties and restoring forces and will not crack or become brittle over time. Used for many critical sealing, insulating and damping applications.
Click here to view/download product brochure
ZOUCHmask 1199
ZOUCHmask 1199 is a crepe paper, coated with a rubber-based pressure-sensitive adhesive. ZOUCHmask 1199 is a proven industry leading tape that is a fantastic all-round masking tape. It is designed primarilly as an all-purpose product for non-critical applications within the building, painting and D.I.Y market.
Click here to view/download product brochure
ZOUCHmask 1210
ZOUCHmask 1210 is a high-quality blue creped paper masking tape. The special adhesive provides clean removability from a wide variety of surfaces, for up to 14 days. This product offers excellent UV resistance. ZOUCHmask 1210 is designed primarily as an all-purpose product for non-critical applications within the building, painting and D.I.Y market; this tape is excellent for even the most demanding of paint application.
Click here to view/download product brochure
ZOUCHmask ST 65
ZOUCHmask ST 65 is a high-quality single-sided polyethylene tape with serrated edges for easy tearing. This product is highly conformable and flexible, offers 30 day clean removal and bonds well to glass, aluminium, plastic and wood. ZOUCHmask ST 65 is designed primarily as an all-purpose product for outdoor masking applications, stucco and plaster masking as well as for surface protection.
Click here to view/download product brochure
ZOUCHseal 90
A single-sided super soft low density semi-open cell lightweight PVC Foam sealant with a very smooth finish which will conform to irregular surfaces and curves. Very high ageing and UV resistant product with a low force to compress. “Quick Roll” enables rapid and improved working and eliminates stretching during installation. Used for sealing air and condensation when compressed, cushioning, gap filling or as a light, dust and draught seal.
Click here to view/download product brochure
ZOUCHseal 100
A single-sided low density soft PVC Foam sealant with mostly closed cells and a very smooth surface. The tape provides an excellent combination of flexibility and conformability and is used for all kinds of indoor and outdoor sealing applications. The special design of the tape “Quick Roll” enables rapid and improved working and also prevents stretching during installation. Very high ageing and UV resistant product used for sealing, insulating for heat and cold, protecting and soft storing applications.
Click here to view/download product brochure
ZOUCHlen 110
A single-sided low to medium density physically cross-linked Polyethylene foam with closed cells which is appropriate for sealing, insulation, protecting and soft storing applications. Will seal out condensation, air, light and dust. ZOUCHlen 110 is ideal where cost is a critical factor.
Click here to view/download product brochure
ZOUCHseal 160
A single-sided medium density flexible PVC Foam sealant with mostly closed cells and a very smooth surface. Often used in HVAC applications for sealing and cushioning and for truck cab & body seals. It has excellent dimensional stability and insulates against temperature. The tape provides an excellent combination of flexibility and conformability with both strength and wear resistance as a main factor. It will perform in those “tough duty” applications where a tape must still be flexible to fit and seal. The special design of the tape “Quick Roll” enables rapid and improved working and prevents stretching during installation. Again, like the majority of our ZOUCH insulation tapes, the ZOUCHseal 160 is totally UV stable.
Click here to view/download product brochure
ZOUCHlen 122
Consists of a single-sided physically cross-linked flexible low density Polyethylene foam with closed cells and an EVA additive to give the product extra elasticity. The product is used for sealing, cushioning, and sound absorption and also serves as protection and insulation. The EVA foams are generally more resilient, tougher and stronger than the conventional Polyethylene foams.
Click here to view/download product brochure
ZOUCHminium
A single sided high quality pure aluminium foil tape which is electrically conductive. ZOUCHminium serves as insulation in heating and air conditioning as well as for isolation, vapour barrier or as a heat, ray and light reflector. The product has a very good working temperature range and can be made available with a pure acrylic adhesive system or a general purpose rubber based adhesive system. Available from 30 micron up to and including 180 micron thickness self wound or with a silicone protective release liner.
Click here to view/download product brochure
ZOUCH WCT 3100
ZOUCH WCT 3100 is a utility grade poly-coated cloth duct tape, ideally suited for joining polythene and has many uses in numerous industries. This is our most popular cloth tape and has been the industry favourite for many years. Available in the following colours: - Silver, black, white, red, blue, yellow, green, brown, orange, tan and olive.
Click here to view/download product brochure
ZOUCH WCT 3120
ZOUCH WCT 3120 is a medium performance, strong, polyethylene coated waterproof cloth tape, coated with a pressure sensitive adhesive. This tape is used in a wide variety of applications, from duct sealing, heavy duty export packaging, double glazing unit sealing, carpet joining and fixing of cables and wires – it is ideal for general purpose applications where added strength and performance is required. The tape is available in a full range of colours including black, white, silver, grey, red, yellow, blue, green and brown.
Click here to view/download product brochure
